Operation Guide: How to Replace the Galvanometer Scanner Mirrors & How to Calibrate it ?

This video will provide you with more details about how to replace the galvanometer scanner mirrors and how to calibrate it. 00:00 - Opening Screen 00:04- Galvo Motors & mirrors 00:10 - Remove the Galvanometer Housing 00:22 - Record the Original X Y-axis Motor Height 00:25 - Remove the Drive Board & Rainbow Cable 00:32 - Remove the X Y-axis Motors 00:43 - Remove the X Y Mirrors 00:50 - Install the new X Y Mirrors 01:00- Connect the X Y Motors to the Drive Board 01:09- Install the Galvanometer Housing 01:14- Level Calibrate 01:18- Install X Y Motor 01:34- Power on Test 01:44-Confirm the mirrors has self-locked 01:50-Switch on the laser 01:56-Install the Field Lens 02:07-Adjust the X Y Motors ' Height 02:12-Start the Machine & Calibration by Line 02:20- Install the Drive Board 02:50- Install the Upper Cover 03:00-Test Laser Marking&Engraving:    • Laser Marking&Engraving   Laser Cleaning:    • Laser Cleaning   Laser Cutting&Welding:    • Laser Cutting&Welding   For other questions, just leave comment below! ___________________________________________________________________ Don't forget to subscribe to our YouTube Channel. Follow us: https://www.sinogalvo.com   / sino-galvo-technology-co-ltd-1962050540532325  """
