How to make a fire detection system using arduino and flame sensor || Techie Lagan

How to make a fire detection system using arduino and flame sensor. Code:- https://drive.google.com/file/d/13t8M... Circuit Diagram:- https://drive.google.com/file/d/1w8w5... _____________________________________________________ Connections:- 1. Connect the GND pin of the sensor with GND pin of the Arduino. 2. Connect the VCC pin of the sensor with 5V Pin of the Arduino. 3. Connect the DO pin of the sensor with the Digital Pin 11 of the Arduino. 4. Connect the negative pin of the Buzzer and both LEDs to the common GND of the Arduino. 5. Connect the Positive pin of the Buzzer with the Digital Pin 12 of the Arduino. 6. Connect the Positive pin of the Green LED with the Digital Pin 6 of the Arduino. 7. Connect the Positive pin of the Red LED with the Digital Pin 5 of the Arduino. _____________________________________________________ Materials Required:- 1. Arduino UNO - https://amzn.to/3MasK4x 2. Flame Sensor Module - https://amzn.to/3OlmfxC 3. LEDs - https://amzn.to/3EkTpsG 4. Buzzer - https://amzn.to/3McqDNA 5. BreadBoard - https://amzn.to/37uxKlM 6. Jumpers - https://amzn.to/3JV8NwZ 00:00 - Intro 00:07 - Materials Required 01:08 - Uploading Code 01:43 - Connections 04:14 - Explaination of Circuit and Potentiometer 05:39 - Demonstration 05:55 - Outro Products I use: 1. Laptop(HP pavillion 15): https://amzn.to/3LnHsFg 2. Keyboard: https://amzn.to/3Ko2Mt0 3. Gaming Mouse: https://amzn.to/3KkFRyI 4. Phone: https://amzn.to/38us6Ac 5. Maono AU-400 Lavalier Mic: https://amzn.to/3OCyPJd 6. Gaming Earphone(SpinBot BattleBudz) : https://amzn.to/3OFH07l 7. Boat Airdopes 121 pro - https://amzn.to/3UWxrTS 8. Tripod - https://amzn.to/3hPBEuB =================================== Thanks For Watching ✅LIKE ✅SHARE ✅ COMMENTS✅ SUBSCRIBE #FireSensor #FireAlarm #ArduinoProject #flamesensor #firealarm #firealarmproject
