MOCON Film Testing Cartridges for Next Gen OTR/WVTR Analyzers | AMETEK MOCON

Click here to learn about the many film cartridge options available for our Next Gen Permeation Analyzers, made to fit many applications and meet the different challenges of testing a variety of film types: https://www.ametekmocon.com/products/... Multi-Use Film Test Cartridges are designed to test a wide range of sample types and ensure accurate, repeatable results. All cartridges are interchangeable between OTR and WVTR for precisely controlled RH testing, with optional 100% RH testing version for WVTR: Standard 50 cm2 Film Test Cartridge - This standard-size cartridge makes it easy to prepare and mount samples on your workbench Extra cartridges allow staging of samples to increase lab throughput Options for both two and four-cell instruments Reduced Area Film Test Cartridge - for higher permeation materials or limited sample sizes, this reduced area cartridge extends the upper detection level of your analyzer. Cheaper, less labor-intensive and more accurate than using aluminum foil masks No adhesive required - allows reuse of sample Edge Effect Film Test Cartridge - this cartridge allows accurate testing of barriers with inherent leakage through the edge, such as coated paper materials. Unique “Dam” design seals the edge of the sample from ambient air or moisture Options for both two and four-cell instruments High Temperature Film Test Cell - this remote film test cell is designed for use in environmental chambers and allows testing at higher temperatures. Central clamping point provides accuracy and repeatability Sample test area: 50 cm2 Specialized Film Test Cartridges are cartridges designed to test a wide range of sample types and ensure accurate, repeatable results: Remote Testing Cartridge Adaptor - this cartridge adaptor fits into your instrument to allow testing with a remote film test cell or package testing fixtures. Allows for easy access to fittings while installed Adaptor requires drawer with removable gate Contact Lens Test Cartridge - this special test cartridge is designed to hold contact lenses for OTR testing. Sponges allow 100% RH testing environment Allows accurate and repeatable gas permeation testing of contact lens Blister Testing Cartridge - this special cartridge is designed to test blister packages. Options available to test pre-filled or empty blisters Pre-filled cavity size: 0.650” tall x 3.1” diameter (1.651x7.874 cm) Empty cavity size: 0.570” tall x 3.022” diameter (1.448x7.676 cm) PackRack Package Testing Fixture - the PackRack expands the testing capability of film permeation analyzers for easy and accurate testing of complete packages. Multi-Use Package Test Cartridges are designed to test a wide range of package types and ensure accurate, repeatable results. Standard 80 cm2 Package Test Cartridge - this standard package test cartridge allows a wide range of packages to be tested. Uses thin foils with sweep gas hole for package mounting Perimeter clamp design holds test foils to the fixture Single-use foils eliminate need to remove epoxy from plates Truseal® flush ring at perimeter ensures a leak-free seal Package Adaptor Cartridge - this base cartridge allows testing of complete packages, unique package types and closures. Vertical fittings for package test configurations Capture Volume Test Cartridge - these capture volume test chambers are ideal for pre-filled sample testing. Stainless steel sanitary clamps for simple set-up Range of sizes to fit a wide variety of sample types Includes Nylon and Teflon seals for OTR & WVTR testing Tooless opening for easy sample insertion and removal Film Test Cartridge (for package test instrument) - this cartridge allows testing of traditional film or NIST films samples on a package testing instrument or fixture. Standard 50 cm2 sample test area Incorporates Truseal® to minimize leakage effects Package Test Chamber - the Test Chamber Cartridge is designed to test empty packages, with a large vertical cylinder chamber for the test gas. 80 cm2 base with foils for package mounting Inlet valve at bottom and vent at top Seal at base for cylinder and refillable water well Applications 100% RH test gas conditions Higher than ambient O2 or CO2 test gas Introduction: 0:00 Reduced Area Film Cartridge: 0:24 Edge Effect Film Cartridge: 1:46 Blister Cartridge: 2:40 Contact Lens Cartridge: 4:00 Package Adapter Cartridge: 4:45 PackRack Package Testing Fixture: 5:51 Closing: 6:20 Visit our website https://www.ametekmocon.com for more information and resources.
