How to model Planetary Gears; Requirements, Gear Ratios, Helical/Herringbone (Gears pt 5/7)

I show how to model a ring gear, how to set up planets, carrier and sun, joints and motion links, and making helical/herringbone sets. I'm using Fusion360, though it should work fine in other CAD software, and I 3D print the set to show you that it works. Files: https://www.thingiverse.com/thing:465... Playlist with all my gear tutorials:    • All about gears   Further reading: Mathematically perfect ring gears: https://khkgears.net/new/gear_knowled... Willis equation for when all 3 gears move: https://www.tec-science.com/mechanica... Instagram:   / creo_nova   Website: https://www.creonova.nl/ Timestamps: 0:00 Introduction 0:28 Modelling ring gear 1:47 Adding a regular gear 3:54 Setting up motion link 4:58 Examining interference between pinion and ring gear 7:43 Making ring gear with proper backlash and clearance 11:12 Checking meshing with new ring gear 11:58 Turning mechanism into planetary gearset 21:25 3D printed planetary gearset 22:02 Comparing planetary gearset to regular spur gear 22:53 What happens if you don't correct addendum/dedendum 23:32 Mathematical requirements for working gearset 28:08 Gear ratios in planetary gears 30:03 Making helical planetary gears 32:31 Making herringbone planetary gears 34:01 Warnings for helical/herringbone planetary gearsets 35:49 Outtro touching story
