UltraHorn Carrier Class, UH-CC-5-24 - UNBOXING

RF elements UltraHorn™ TP 5-24, UH-TP-24 is the ultimate noise-rejecting horn sector and point to point antenna for 5 GHz unlicensed networks. Product page: https://bit.ly/38ahYNv Datasheet: https://bit.ly/33kCVzj Where to BUY: https://bit.ly/3DT8UX7 UltraHorn™ (UH) solves the biggest issues in the unlicensed bands - that of RF noise, system loss, and network scalability. UH comes assembled out of the box and all you need to install the antenna is a 13 mm wrench. UH has 24 dBi gain, 15 degrees beamwidth and the following features make it an ideal PTP or PTMP narrow sector antenna in the unlicensed 5 GHz band: The radiation pattern of UltraHorn™ is symmetrical - with the same beamwidth in the azimuth and elevation cut. UH is the ultimate antenna in terms of noise rejection - there is only one main lobe and zero sidelobes and its BE is 99 %, which is a unique feature unmatched by any other PTP, or sector antenna in the wireless industry. If you want to know more about BE, you can check our short video:    • Inside Wireless: Beam Efficiency Definition   The maximum gain is stable over the whole useful bandwidth so the signal strength is constant regardless of the frequency channel used. Also the rest of the radiation pattern is stable over the useful bandwidth providing high coverage stability and reliability especially for the CPEs at the edges of the sector. The Horizontal and Vertical radiation patterns are identical, which is yet another addition to the reliability of the UH performance on both radio chains. UH features TwistPort™ - our proprietary waveguide connector that minimizes the RF power loss occurring between a radio & the antenna. Thanks to these favorable properties, you can: Co-locate many UH even on a crowded tower without any degradation of links already in place. All of that with no additional cost for aftermarket shielding kits thanks to the 99% BE and narrow beam width. The side lobe connection typical for parabolic dishes when you see a decent signal strength is extremely easy to avoid with UH - one main lobe and zero sidelobes leaves no space for error. There is only one azimuth angle with the maximum signal that clearly indicates correct alignment. So is UH a PTP or a Sector antenna? It depends on the scenario. UH is an excellent PTP antenna if it fits your need, as well as a narrow sector antenna, for example with customers clustered close to each other far from the tower. Thanks to the larger elevation beamwidth, UH easily covers the null zone at the site and the coverage is reliable in flat to somewhat hilly landscapes. In mountainous regions, the wide downtilt range (+- 25 deg) helps you aim the spotlight at the cluster of CPEs. UH is equipped with TwistPort™ - our proprietary waveguide connector with near zero insertion loss, which can save even 3 dB of radio power. TwistPort™ is extremely user-friendly and enables fast installation of a radio with one hand. The TwistPort™ eco-system also makes migration to other radio platforms easy and economical. All you need to do is to change the adaptor to fit the new radio and you can keep using the same antenna. Twistport™ - our proprietary waveguide connector with near zero loss connects and mounts the radio within seconds. Twistport™ ecosystem makes migration to other radio platforms easier and economical - simply change the adaptor to fit the new radio and you’re done. UH weighs 8.2 kg and its body has a beautiful matte finish. UH will withstand extreme environmental conditions - it is built from premium materials: die-cast and extruded aluminium, UV-resistant plastic, and stainless steel hardware with a black colored surface coating protecting the bolts from seizing and extending durability of the whole bracket. At the edge of the aperture is a water drain hole so the condensed water simply leaks out. There is absolutely no assembly involved - UH comes pre-assembled from the factory. Our innovative UH bracket which is part of the package is optimized for durability and easy installation. Before you attach the bracket arm on the tower it is useful to know the thickness of the pole - if its diameter is smaller than 58 mm, position the bracket as shown. For diameters larger than 58 mm, flip the bracket for the best attachment. The four long M8 bolts ensure robust and durable attachment. 0:00 Unpacking 0:19 Pole installation and aiming #RFelements #UltraHorn #Beamefficiency #Twistport #WeHaveHorns #SymmetricalHorns #WirelessLink #WirelessBroadband #WirelessInternet #RuralBroadband #fixedwireless #WISP #ISP #SectorAntennas #RuralInternet #PTP #PTMP #5GHz #6GHz
