CATIA V5 Part Design: Master Point Creation #1 (Coordinates, Between & On Curve)

Welcome to lesson 13. We begin our deep dive into the Reference Elements toolbar in CATIA Part Design. This essential first part focuses on the foundational methods of the Point tool. Learn how to use Coordinates for precise spatial placement, the Between method for relational points, and all the critical sub-options of On Curve. We also unlock the secret difference between Geodesic (on the curve) and Euclidean (chord) measurement modes. Key Topics in this Lesson: Coordinates, Between, On Curve (Distance/Direction/Ratio), Geodesic vs. Euclidean. 🔔 Don't forget to practice along! Subscribe and watch Module 14 next for On Plane and On Surface methods. 🔗 **Full Playlist Link: https://www.youtube.com/playlist?list... 00:00 - Introduction to Reference Elements Toolbar & Point Tool 03:22 – Describing the point definition window 04:15 - Point Creation Method 1: Coordinates 05:34 - Using Coordinates and Axis System Reference 09:11 - Point Creation Method 2: Between (Ratio & Middle Point) 13:37 - Point Creation Method 3: On Curve – Distance on Curve 15:25 - On Curve: Distance along Direction (Defining a new Axis) 18:43 - On Curve: Ratio of Curve Length 19:35 - Critical Concept: Geodesic vs. Euclidean Measurement Explained 21:00 - Summary and Link to Part B Contact each other and solve problems: t.me/MikeCATIA
