OSIsoft: Upgrade to PI Server 2016: Full Walk-through (from version 3.4.380.70 64-Bit)

This video shows step-by-step how to upgrade to PI Server 2016 (AF Server Version 2.8.0.7444 & Data Archive Version 3.4.400.1162). The SQL Server was installed previously (   • OSIsoft: Install SQL Server 2012 Express w...  ). Use the video timestamps below to SKIP AHEAD to specific sections. [00:11] Previously checked prerequisites, downloaded install kits, verified health and correct buffering configuration, and installed SQL Server [00:50] Navigate to livelibrary.osisoft.com [01:19] Review install procedure for components on same server or multiple servers [02:03] Confirm necessary Local Administrator and SQL permissions- SysAdmin privilege is required ----PI AF Server Installation (PI AF applications service and PI AF SQL database)---- [03:30] Run the AF Server Install kit as administrator [03:52] Specify installation files extraction path if desired [04:00] Reminder Microsoft .NET Framework 4.6 will require a machine restart and .NET Framework installation [05:20] Select features- Install AF application service and AF SQL database [05:49] Logon Information- Choose virtual account for components on same machine, domain user account for components on separate machines [06:14] SQL Server Connection- specify named instance from prior video [06:42] AF server installation completes [07:00] Verify PI AF Application Service in Services console and PIFD database with SQL Server Management Studio ----PI SMT Installation---- [07:53] MDB requires to first run MDB to AF Preparation Wizard [08:17] Download PI SMT 2016 from techsupport.osisoft.com [09:00] Run the PI SMT Install Kit as administrator [10:10] Open PI SMT and navigate to Operation, AF Link [10:50] Complete the MDB to AF Preparation Wizard ----PI Data Archive Upgrade--- [12:40] Isolate PI Data Archive from network during the upgrade [13:04] Add new firewall rules for PI Interface IP addresses to PI Firewall in PI SMT [13:28] Stop PI Data Archive using cmd with pisrvstop [14:15] Verify that data is being successfully queued by PI Buffer Subsystem on PI Interface nodes [15:55] Run the Data Archive install kit as administrator [16:45] Default Asset Server- Verify default AF Server [16:59] Data directories- keep default for future archives [17:33] Installer completes and starts PI Services ----Post Installation Tasks---- [17:58] Check Operation, PI Version in PI System Management Tools (PI SMT) [18:25] Confirm all PI Services are running in PI SMT [18:37] Check archive and snapshot health statistics [19:00] Confirm default PI Points have current values [19:31] Check license expiration time and current percent match ----Reconnect PI Data Archive to PI Interfaces---- [19:57] Delete PI Firewall entries for the PI Interfaces [20:13] Stop and start PI Data Archive to apply PI Firewall changes [21:03] Verify buffering reconnects on PI Interface nodes, queues flush, and PI Points are updating ----Wrap up---- [22:30] Confirm MDB to AF is "In Sync" [22:44] Install the PI Analysis Service [24:45] Additional learning playlists Video content is copyright of OSIsoft, LLC © 2016. All rights reserved. Any redistribution or reproduction of part or all of the contents in any form is prohibited other than for your personal and non-commercial use.
