Pomati Group | Carrello Basculante Tinting belt

Tilting Enrobing Belt Loading net with start/stop system Covering net with product vibration area Unloading strip with start/stop system powered by paper roll Folding structure Aluminium tray for product unloading Bearing plane for product unloading Double-coat hopper for complete covers Electronic control of ventilation Blower adjustable in height and tilt End cutter Pool for lower and side cover (optional) Strip length mm 180 (mm 250 version also available) Electronic control of net speed 0-2 m/min. Volt 230 – Hz 50 – Kw 1,2 single-phase – (special voltage upon request) Size when open H 1030 L 1820 P 450 Size when closed H 1890 L 500 P 450 Three-section covering strip assembled on tilting cart. The tilting air blower allows left and right height adjustment. It is possible to adjust the distance between the end cutter and the conveyor to streamline the transit of coated products smaller than the standard, spherical or irregular-shaped products. The loading net can be stopped to improve the accuracy and the timing of product positioning. The covering net is equipped with adjustable vibrator to streamline the surface of the product and a blower with variable speed with filter to regulate the weight. The covering speed can be controlled electronically from the operator’s panel. Available for: mm 180: T8/T10/T20/T35 mm 250: T20/T35 Let's keep in touch! Website | http://www.pomati.it/ Email | info@pomati.it Instagram |   / pomatigroup   Facebook |   / pomatigroup
