CAD 101 - AutoCAD - Advanced Draw and Modify - Part 2 of 5

Welcome back to CAD 101 – AutoCAD. In Part 2 of Assignment 2 (Advanced Draw and Modify), we complete Drawing 2 of 5. This drawing reinforces precision layout using offsets to digitally simulate machining operations. In this video, we focus on: Creating a 6" x 6" square using absolute + relative input Using offset to establish construction lines Creating circles using Center-Diameter Applying object snaps (intersection + midpoint) Cleaning up reference geometry Building top and right orthographic views Understanding symmetry in projection Reinforcing 0.5" material thickness This drawing introduces multiple hole features, including: (4) 0.25" diameter corner holes (1) 5" diameter centered hole Proper layout spacing using offsets ⚠️ Dimensions and centerlines are demonstrated conceptually but not required yet for submission. 📂 File Naming Format LastName_CAD101_001_A2_D2 📤 Export Format DWF 🔑 KEY TOPICS AutoCAD, Offset Tool, Circle Center Diameter, Object Snaps, Intersection Snap, Orthographic Projection, Engineering Drawing, CAD 101, CTE Engineering, DripKingEngineering ⏱️ TIMESTAMPS 00:00 – Assignment 2 Overview (Part 2 of 5) 00:20 – Save As & Updating Title Block 01:11 – Analyzing Drawing 2 02:28 – Creating the 6" x 6" Base Square 04:07 – Using Offset for Hole Layout 05:49 – Creating the 5" Center Hole 06:34 – Creating the Four 0.25" Holes 07:48 – Cleaning Up Construction Lines 08:37 – Building Top & Right Views 10:58 – Calculating Offset Distances for Projection 12:49 – Understanding Circle Projection Geometry 15:22 – Optional Centerline Discussion 15:59 – Wrap-Up & Next Drawing
