How do I connect item profiles with Standard Fastening Set K – ideal for enclosing panels?

This video shows how to connect item profiles using the Standard Fastening Set K. How do you connect item profiles at right angles – with open grooves on all sides? The item Standard Fastening Set K allows you to connect profiles at a 90° angle without affecting the surrounding grooves. This is ideal for applications where panel elements need to be flush-mounted, e.g. in protective covers or enclosures. What are the advantages of using the Standard Fastening Set K? Open groove on all sides – no reworking necessary Plastic spacer minimises installation space Easy processing: thread + mounting hole What is the assembly principle? 1. Cut a thread into the core hole of the first profile 2. Drill a mounting hole in the second profile 3. Insert the connecting screw in a fixed position – done! Video content on connecting aluminium profiles with the standard fastener K at a glance: 00:00 Intro The image shows a section of the assembly. 00:05 Step 1: Through hole is drilled in the first profile A 7 mm diameter through hole is drilled 20 mm from the end face into profile 8. 00:21 Step 2: Core hole in the second profile is countersunk The core hole in profile two is countersunk using the cordless screwdriver. 00:28 Step 3: Threaded hole is drilled on the front side An M8x18 thread is cut into the core hole of profile 8 using the cordless screwdriver. 00:50 Step 4: Standard Fastener K is assembled and the spacer is fitted The Standard Fastener K is pre-assembled and screwed into the threaded hole (A/F 5 mm) so that there is still a little play. 01:14 Step 5: The two item profiles are screwed together using the through hole The two profiles are screwed together through the through-hole (A/F 5 mm, 25 Nm). The following products were used in the video: 1. Profile 8 40x40 E: http://i24.ws/7000009 2. Standard Fastening Set 8 K: http://i24.ws/48807 ► MORE TIPS AND TRICKS FOR ITEM PRODUCTS: https://academy.item24.com --- ► BUILD ONLINE NOW: https://tools.item24.com/DEen/tools/e... --- ► If you enjoyed watching our video or want to tell us what you think, please leave us a comment. --- For more information and to check out example applications showing how you can make your production operations more efficient, subscribe to our channel, or visit us at: ► Website: https://de.item24.com/en ► Shop: https://www.item24.com/en-de/ ► Blog: https://blog.item24.com/en/ ► LinkedIn:   / item-industrietechnik-gmbh   ► Facebook:   / itemworldwide   ► YouTube:    / item24com   #Instructions #tutorial #assembly #standard fastener k #connecting two profiles at right angles #enclose panels The video was recorded on 2019-03-07 15:00:00.000 and is valid until further notice. The description was updated on 2025-09-12 15:30:00.000. This video was produced by the manufacturer of the products used: item Industrietechnik GmbH Friedenstraße 107-109 42699 Solingen Related videos: Standard Fastening Set:    • How to connect aluminium profiles at right...
