repulsive magnetic levitation , "qaqish oscillator" with 3 electronic components & one coil

qaqish repulsive magnetic levitation oscillator , " qaqish oscillator " repulsive magnetic stand up levitation very simple with one coil just 3 electronic components hallsensor 49E7318C every resistor from 1k to 470k can take , all works the same i take 470k Mosfet , IRF 540 N , n-channel coil 7-10 ohm , 20x20x4mm loudspeaker magnet ring , 80x40x15mm alu stick 45x4mm center up the coil and is to ajust for the level . voltage work : 10-13 Volt ajustable current , about 200 mah my levitation distance is about 10 mm , because more current forces and very strong quader gold magnets 5x5x1mm for brusless-motors with other coils & magnets dimensions , you will reach more levitate distances . this circuit is very reduced as possible and show the simple prinzip of levitation , with just one coil all hallsensors , resistors and mosfet-transistor can be used , this circuit is not critical , the main thing are the coil ohm and voltage and the balance setting of magnetic forces together same prinzip can be build larger . lower ohm of the coil , its wear more weight , but use more current , to go the low current way , it need more ohm coil , about 26-30 ohm , current will be about 100mah by 10 volt , it is better to build in a 5 volt stabilisator IC , just for the hallsensor ,so this do not go hot , but till 13 volt the hall work stabil the Ringmagnet polarity is on the bottom north , on the top south coil is the same levitation magnet is convert , north on the bottom and south on the top it works by exactly weight of the magnets , not to much , not to less 3 magnets 5x3 works well or quader magnets 5x5x2 , 5-6 parts electromagnet attracts magnet it is also possible to change all polarities , it works same . in this case , if the hall sensor can build deeper in the coil , the electric coil magnet field influences the Hall sensor a bit for a lower current start , and if you use 5mm plastic washer between electro-magnet and bottom ( set the coil higher ) , the current falls to 90 mah and need just 9 volt . levitation altitude is 8 mm with the 7 ohm coil . the coil is by this low current 90mah perfect durable cold and the levitate strong gold edition magnet is dancing like a dancing queen , because all forces are very low . at last i find out , that was the best low current device . this is my lastest update remark ! with three small 5x3 neodymagnets ( move and ajust on the top side of the ringmagnet) , you can center up also the levitated magnets exactly in the middle point of the electromagnet . case of permanent spinning this is my discovery for this oscillator "qaqish oscillator" qaqish repulsive anti gravity levitation spinning oscillator , i have never see such permanent spinning of a magnet , the square magnet works and find his own speed spinning point through all phases after hit the rotor magnet , by the moment with 90 degree he find the right feedback in every harmonic wave , phase looked loop point for self switching/ ignition , like all oscillators , franklin , meißner , collpitts , clapp, hartley, pierce , miller, butler , pull-push , wien bridge generator, Esaki Oscillator and so on . why magnet spinning ? setting the right voltage , asymetric setting of the main magnet with coil and hallsensor , so the magnet levitate in a diagonally position . the four corners and straight flanks have different lengths to the hall sensor , therefore they hit him for permanent spinning . new update video here from 18.2.2020    • repulsive magnetic levitation & spinning "...   wish much luck to build it . my inspirator is the youtube channel : Hobby Projects link :    • Very Simple Repulsive Magnetic Levitation ...      • Repulsive Magnetic Levitation using Arduin...      • Repulsive magnetic levitation - Simple design
