Antenna Dipole for 27 MHz / 11 Meter Band / Citizen Band / HF Tutorial

How to make and measure the dimensions for a Dipole Antenna for 27 MHz / Citizen Band / 11 Meter Band / High Frequency with the help of the NanoVNA antenna analyzer. Lengths: 1. 5/8-inch aluminum tubing, 12 cm long 2. 4/8-inch aluminum tubing, 169 cm long 3. 3/8-inch aluminum tubing, 74 cm long 4. 1/2-inch T-shaped PVC tubing 5. 1/2-inch straight PVC tubing 6. 1.5-meter RG58 Co-Expression for Choke Balun 7. 1.25-inch PVC tubing, length adjusted to accommodate Choke Balun 8. Male Connector 9. Bolts Analysis results using the NanoVNA antenna analyzer are: 1. SWR = 1:1.00 at a frequency of 27.440 MHz 2. Impedance = 49.9 Ohms with 2.04 nH (Nano Henry) 3. LogMag (attenuation) = Equivalent (-) 47.47 Hopefully, this information is useful and can motivate you to try building your own antenna. Dipole antennas are simple and cheap. What a Beautiful Day Link Sigma 4 Antenna for 50 MHz / 6 Meter Band / Magic Band:    • Sigma 4 Antenna for 6 Meter / 50 MHz / Mag...   Link Sigma 4 Antenna for 27 MHz / 11 Meter Band / Citizen Band: https://www.youtube.com/watch?v=Z-7rD... Sigma 4 Antenna link for 144 MHz / 2 Meter Band: https://www.youtube.com/watch?v=U50l2... Link Sigma 4 Antenna for 144 MHz / 2 Meter Band + Phase Inverted:    • Sigma 4 (BT-104) Antenna for 144 MHz + Siz...   Link Delta Loop 7 elements Antenna for 144 MHz / 2 Meter Band : https://www.youtube.com/watch?v=p257c...
