Modeling 3D random RVE of unidirectional composite: Abaqus Plug-in

In this video, we will discuss about a unique plug-in for creating 3D random RVE of unidirectional fiber reinforced composite materials. This plug-in is capable of creating an RVE with high volume fraction up to 80 percent through combining three fiber placement algorithms, creating an RVE using embedded region, merge or voxel-based methods, considering the periodicity of the RVE, assigning material orientation to the fibers automatically, creating an RVE with randomly sized fibers. Using another EngSoft plug-in EngSoft_PBC3D_V2 or EngSoft_PBC3D_V1 the model is ready for submitting the job. 00.00,01.09 Introduction 01.09,03.31 Using plug-in to create an RVE with merge technique 03.31,05.10 Using plug-in to create an RVE with merge technique 05.10, 07.25 Using plug-in to create an RVE with merge technique 07.25,09.25 How to apply PBC by EngSoft_PBC3D_V2 Related video and products: engssoft.com    • RVE of unidirectional composites or circul...      • Abaqus Plug-in to apply periodic boundary ...
