SETAF2018 – Defining Rigid Columns Under a Rectangular Foundation

In this video, the steps for defining rigid columns under a rectangular foundation, editing column dimensions, and reviewing the rigid column group in 3D in SETAF2018 are explained. 🔹 Opening the Foundation Properties window using Selection Mode 🔹 Enabling the Deep Foundation Soil Improvement option 🔹 Selecting the rigid column type (cast-in-place pile, concrete pile, micropile, jet grout, deep mixing) 🔹 Defining column spacing (Sx–Sy and m–n column counts) 🔹 Entering column diameter and column length 🔹 Entering elastic modulus and Poisson’s ratio 🔹 Reviewing the factor used for tip bearing capacity 🔹 Checking automatically calculated section area, perimeter, block area, and block perimeter 🔹 Applying the changes using the Apply buttons 🔹 Viewing rigid columns under the foundation in 3D 🔹 Using the View menu to filter soil layers, boreholes, and foundation visibility 🔹 Quickly resizing the rigid column group by editing spacing, length, and column counts 🌐 More information: https://www.setaf2018.com 📩 Support: info@setaf.org
