Onkyo TX-330 Solid State Stereo Receiver Japan 1974

A beautiful and dignified receiver from 1974, the golden area of Japanese home audio production. Silver / champagne front panel, real smoked glass tuner screen and metallic framing make the TX-330 a serious HiFi item. The wooden housing gives the receiver a warm charm. The receiver has a truly outstanding FM sensor with FM Muting feature that gives a smooth scroll on the scale. The amplifier delivers around 17–20+ watts per channel into 8Ω with wide frequency response (approx. 20Hz to 30kHz). High-fidelity, clear, and dynamic sound. Versatile for its time, including Phono (turntable), AUX, and dual tape inputs. This is a heavy weight unit, over 10 kg. This item is a completely cleaned and tested receiver with all functions promptly working, all parts are original from 1974. International shipping in a hard cardboard box, carefully and safely lined. Specifications: Manufacturer: Onkyo Model: TX-330 Serian No: 86021874 Type: Receiver Years of manufacture: 1974 - 1976 Manufactured in: Japan Color: Silver / Champagne / Wood Dimensions (WxHxD): 470 x 140 x 375 mm Weight: 10.5 kg Connections: Number of inputs: 1 x Phono 2,5mV/50kOhm 1 x AUX 200mV/50kOhm 2 x Tape Play 200mV/50kOhm 2 x Tape Rec 200mV/100kOhm 1 x Mic 4mV/50kOhm Coaxial FM- antenna connection (75 Ohm) AM- Antenna connection Number of outputs: 2 speaker pairs Headphone output 6,3 mm jack plug Technical data: Amplifier: Continuous power (at distortion factor) 8 Ohm: 2 x 17 W 4 Ohm: Dynamic power 8 Ohm: 4 Ohm: Total harmonic distortion: 0.5% Frequency response: 20 KHz - 30 KHz +- 1 dB Signal-to-noise ratio: 65 dB (MM), 80 dB (Line) Tone control: Bass: yes (± 10 dB at 100 Hz). Treble: yes (± 10 dB at 10 kHz) Loudness: yes Tuner: Reception: FM, MW Frequencies: FM: 88 - 108 MHz MW: 550 - 1,605 kHz Frequency response: -FM: 30 - 15,000 Hz (± 0.5 dB). Input sensitivity: FM: 1.8 µV (IHF) MW: 40 µV Distortion factor: FM: 0.2% (mono), 0.5% (stereo). Signal-to-noise ratio: FM: 70 dB MW: 40 dB Channel separation: FM: 40 dB (400 Hz) Co-wave selection: 1.5 dB VHF: 100 dB MW: 40 dB AM suppression: Output level: 50 dB Special Features: Microphone mixer Shipping details in the web shop: http://garyaudio.nl #Onkyo #OnkyoTX330 #Receiver #MadeInJapan #70sHiFi #VintageHiFi
