[Meta Biomed] EQ-V Fill Maintenance Guide

[EQ-V Fill Maintenance Guide] 1. After using the EQ-V Fill, pull the trigger to dispense any remaining GP from the cartridge. (Ensure there is no gap between the plunger handle and the device) 2. Turn off the device and wait until the internal heat cools down (approximately 1 minute). 3. Press the plunger button to pull back the plunger. 4. Unscrew the GP cartridge to detach and remove it. 5. If there is residual GP inside the device, clean the inside using a cleaning brush soaked in alcohol. 6. If the GP has hardened inside the EQ-V Fill and cannot be removed, or if the plunger does not come out, heat the device to 160°C to slightly melt the remaining GP inside, then proceed with cleaning 7. Gently wipe the EQ-V Fill body and plunger with an alcohol wipe. [If GP does not dispense properly or leaks backward from the cartridge: Replace the plunger seal] 1. Turn off the EQ-V Fill, wait for it to cool for approximately 1 minute, and press the plunger button to retract the plunger. 2. Use the seal driver to remove the worn/broken plunger seal at the tip of the plunger. 3. Attach a new plunger seal using the seal driver.
