Sliding Folding System with Low Threshold - Tiara Flat/Slim/Zero

Sliding Folding Glazing Systems with Low Threshold - Tiara Flat/Slim/Zero Folding glazing systems with low threshold Tiara flat/slim/zero have been developed to be used easily for years without requesting any technical service. In malls, restaurants, cafes, and offices, wherever you need a flexible solution to keep your space free when it is opened up, as well as secure and visible when it is closed. Flexible solution for all areas! With Tiara, enjoy the limitless view and open yourself to outdoor life. HOW DOES IT WORK? Tiara system is a Sliding Folding System. The panels slide on the rails with the help of the top and bottom rollers. All the panels can be folded and stocked in the right or left side. In open position, the panels are positioned perpendicular to the rail profile. ADVANTAGES AND TECHNOLOGY OF TIARA 08/10 • All-glass slide-and-turn-system • Wheelchair friendly • No parking station for panels required • 8 mm or 10 mm thickness glass can be used • Max. panel sizes: 800 x 2700 mm • Various opening options are available • Largely prefabricated, therefore short installation times • No vertical frames, save your panorama • External glass surfaces are easy to clean from inside • This products are tested and certified by approval independent testing institutes • Integrated (top&bottom) 2-point lock for child safety/burglar resistance TIARA FLAT The threshold height is 23.3 mm. In passing area, ramp profile provides isolation and allows easy passing. TIARA SLIM The threshold height is 23.3 mm. On balustrade systems, it provides maximum panoramic view with less aluminium profiles. TIARA ZERO The threshold height is 7.3 mm. It provides free passing by using embedded rail profile. Wheelchair Friendly Thanks to the low threshold feature in our profiles, our systems operate with a ramp suitable for wheelchair passage. Hidden Water Drainage On top of the rail profile, there is a condensate channel for water drainage which enables effective rain drop drainage. The raindrops are not allowed to get inside with the help of guidance channels. Unstoppable Movement In Tiara, specially designed and covered rollers are used 4 on top and 4 on the bottom for each panel. This makes the system unstoppable. All panels are opened and closed in comfort with minimum friction and noise. Not Falling and Dropping Panels Albert Genau R&D department engineers developed a new locking mechanism. The system is called “ABL – Auto Brake Lock” and locks itself automatically when the panels fold. It provides panels are not falling and dropping. Extra Safety - Pin System Option The glass is not only mounted into panels with chemicals but also with pins can be mounted into the glass. This allows a safer usage for end users. Esthetic Knob Lock Option Albert Genau designed an optional knob lock mechanism. The knob lock mechanism provides stylish appearance, minimal design, and easy usage. Vertical Profile - More Isolation Providing more isolation and keeping the places away from dust, noise, and water, Tiara vertical (frame) aluminum profiles, do not prevent your view with their thinner design. Angular Conjunction Lamella With smartly designed lamella, perfect conjunction is provided in curved application areas. Height Adjustment Profile Compatible with all Tiara systems, this profile allows an easy, fast and more precise solution for the system installations which need leveling. Panel Fixing Apparatus The panel fixing apparatus is attached to the bottom railing profile to secure stocked glass panels and prevent uncontrolled movement. Safety For Your Child As a standard, on each hinged panel, there is Albert Genau Child Locks. While the system is locked it means your child is protected Passed The Tests! WATER TEST Tiara Balcony Glazing System have been tested by German PfB Technical Institute for water test according to European Standards and achieved Class2A result. WIND PERMEABILITY TEST Tiara Balcony Glazing System have been tested by German PfB Technical Institute for wind permeability test according to European standards and had Class3 result. IMPACT TEST Tiara Balcony Glazing System have been tested by German PfB Technical Institute for impact test according to European standards and had ClassI2/E5 result. WIND LOAD TEST Tiara Balcony Glazing System have been tested by German PfB Technical Institute for impact test according to European standards and had ClassI2/E5 result. Subscribe for more cool videos from Albert Genau For detailed information, visit our website https://www.albertgenau.com/en/Tiara-... Follow Albert Genau on social media   / albert.genau     / albert_genau     / albertgenau     / albert-genau     / albertgenauofficial   https://open.spotify.com/user/on01zux...
