FreeCAD Tutorial #63 — Subtractive Pipe with Multi-Section Explained

Learn how to create a Subtractive Pipe with multiple sections in FreeCAD. In this tutorial, I show how to remove material along a controlled path while smoothly changing the profile shape. Commands Used in This Video 1. Subtractive Pipe The Subtractive Pipe command is used to remove material along a defined path. 👉Action: It sweeps a sketch profile along a trajectory and subtracts that volume from the solid body. 👉Typical Use: Internal channels, curved cutouts, ducts, passages, and complex internal geometry. 2. Multi-Section Subtractive Pipe Multi-Section allows the Subtractive Pipe to change profile shape along the path. 👉Action: FreeCAD blends multiple section sketches smoothly while sweeping along the same trajectory. 👉Typical Use: Tapered cuts, shape transitions (for example, circular to hexagonal), and controlled material removal. 👉Explore the complete FreeCAD tutorial playlist for structured, step-by-step lessons and real-world CAD workflows —    • FreeCAD Tutorial #59— Hole Tool Explained   💬 Need Help? Drop Your Questions Below! 🙏 Thanks for watching! 🔖Tags: #freecad #freecadtutorial #cad #subtractivepipe #freecadsubtractivepipe #multisectionsubtractivepipe #engineeringwithpritam #engineeringwithpritamfreecad
