COMOSYS 2026 - Part 1 Drawing Side Improvements

We are pleased to announce Comosys 2026 with many enhancements. Brief Highlights have been provided here COMOSYS 2026 - New version features Drawing side improvements 1. Single part view overrides in Assembly drawings. Individual control over which views of each single part are drawn. 2. Assembly view overrides for sections taken. Individual control over which sections are created 3. Single part drawing view rotation angle. 4. New Dimension formatting for consecutive short dimensions 5. Adding views and sections and details manually to Automatic Assembly drawings and ensuring they are kept even if the drawing is updated. 6. Model style “On the fly” filtering on “Drawing side” 7. Quick window selection of objects inside viewports 8. Saving Assembly drawings as Presets and loading and using them 9. Intelligent dimensioning of circular cuts and notches 10. New Annotation and Leader text styles 11. New settings for Generic solid dimensioning and annotating in Assembly drawings. 12. New Dimension types (Tail Dimensions) 13. New orientation based Annotations (Near Side, Far side, on Center etc) 14. Annotation grouping for same annotations 15. Multiple legs for welding symbols 16. Cylindrical plate annotation option 17. Drawing side filter to automatically include any holes on an ID when the main part is added. 18. “Ready to be issued” flag added 19. More drawing fields added like “Designed by” etc 20. All fields in Model Settings also checked in Assembly drawings of local settings haven’t overridden them. 21. All custom fields to be available under model settings under an advanced tab rather than in project preferences 22. Cutting plates profiles and generic solids as per up down limits of viewport 23. Elevation dimension option in Assembly drawings 24. New US Style material list 25. Standard part model based numbering. 26. Drawing based part numbering according to US style using UDA’s 27. Recursive copying of objects between drawings or viewports 28. Bolt connection side symbol 29. Open more than one drawing side by side 30. “Do not dimension these position no’s” setting in Assembly drawing Assembly Drawing creation wizard Drawing Side UNDO 1. Drawing side UNDO 2. Entire drawing deletion backup system For more information and discussion about how COMOSYS can increase your productivity by manyfold write to info@ramcadds.in #comosys, #steeldetailing, #rebardetailing, 3Drebar, #connections, #fabrication, #intelliClone, #intelliConnect, #AutoAdjust, #steelConnections, #IFC, #bim, #FEA
