What is Resonant Frequency? - ECS Inc. International

Resonant Frequency is the Oscillation of a system at its natural or unforced resonance. Resonance occurs when a system is able to store and easily transfer energy between different storage modes, such as Kinetic energy or Potential energy as you would find with a simple pendulum. Most systems have one resonant frequency and multiple harmonic Frequencies that get progressively lower in amplitude as they move away from the center. In the case of a Quartz resonators. The resonant Frequency is the desired Frequency of Oscillation that you want to achieve. There are two methods of using Resonant Frequencies to derive a clock. Crystals operating at or below 50MHz are referred to as resonating at their Fundamental or natural frequency. Shown in the graph here in red. When producing clocks that need to generate Frequencies above 50MHz you are taking advantage of Harmonic Frequencies. Harmonics are multiples of the fundamental Frequency. Shown in the graph as 2nd, 3rd, 4th & 5th Harmonic. As an example, a Third harmonic would be three times the original Frequency. In this case the fundamental frequency of 110 hz x 3 = 330 hz. You can isolate and amplify the Harmonics to give you a higher cleaner Frequency than you would if you multiplied the original Frequency. This opens up the available Frequency spectrum to Quartz based resonators. ECS Inc. International 15351 W. 109th Street Lenexa, KS 66219 (913) 782-7787 www.ecsxtal.com engineering@ecsxtal.com
