How To Check Shear Walls Punching Shear Ratio?

In this example, we want to control the punching shear ratio in the shear walls in an approximate way. To do this, we must define an equivalent column similar to the section of the shear wall Also, the bending and axial stiffness properties of the equivalent column should be similar to the shear wall. Then, under the wall and above the equivalent column, we must define a very stiff beam. Finally, we analyze the model and export to SAFE software.In SAFE, we also define and assign the basic specifications necessary for the analysis and design of the foundation, and since our overall goal is to determine the punching shear ratio by the SAFE, other parameters are not important at the moment. Finally, you will see that because the wall cross-section was meshed in ETABS, the punching shear ratio for those walls was not calculated in SAFE. For the equivalent column, we must also enter the size of the load for loads that enter from above, similar to steel structures. If you like the video after watching it, please like it so that it can be shown to more engineers #ETABS#PunchingShear#ShearWallPunching If you want to see my next videos, please activate the bell and subscribe my channel so you don't miss the latest design tips in ETABS Designing Software. Timecodes 0:00 - Introducing Approximately Method 0:40 - Creating Save As File From Main Design File 1:05 - Defining New Stiff Material For Beam And Equivalent Column Section 3:18 - Deleting Beam And Shear Wall and Drawing Equivalent Column And Stiff Beam 4:22 - Modifying Equivalent Property Modifiers For Bending And Axial Stiffness Properties 5:05 - Seeing Equivalent Column In 3D View 6:05 - Run The Model 6:15 - Export To SAFE 7:55 - Defining Material And Slab Thickness And Soil Subgrade In SAFE 9:02 - Draw Slab Of Foundation 9:25 - Assign Size Of Load For Above Loads To Equivalent Column In Safe 12:38 - Modify Concrete Cover In Design Preferences ( Cover = 75 cm ) 13:12 - Run And Design And See The Punching Shear Ratio Results
