Setting up a CFD- and FEA-analysis of a Winglet using Siemens NX, STAR CCM+ and HEEDS

This video shows how I combined a CFD- and stress-analysis using STAR CCM+ and HEEDS. This simulation was part of my master thesis. This means I am not a CFD professional, almost everything was self-taught and there are probably better ways to do certain things. The video shows what worked for me. ######### Chatpers ######### 0:00 - Introduction 0:24 - CAD-model setup in Siemens NX 1:48 - Geometry setup in STAR CCM+ 2:57 - Creating tags 4:23 - Physics setup 5:55 - Region setup 8:03 - Mesh setup 10:11 - Data Mapper setup 12:15 - Constraining model and adding loads 17:43 - Post-processing 20:43 - Stopping criteria and Time scales 23:47 - Common issue and fix 25:14 - Simulation prep for HEEDS (recording macros) 29:03 - Simulation operations 31:29 - HEEDS setup 38:34 - Final result ##########################
