Binary Adder Subtractor - Digital Logic Design

The subtraction of unsigned binary numbers can be done most conveniently by means of complements, as discussed in Section 1.5. Remember that the subtraction A - B can be done by taking the 2’s complement of B and adding it to A . The 2’s complement can be obtained by taking the 1’s complement and adding 1 to the least significant pair of bits. The 1’s complement can be implemented with inverters, and a 1 can be added to the sum through the input carry. The circuit for subtracting A - B consists of an adder with inverters placed between each data input B and the corresponding input of the full adder. The input carry C0 must be equal to 1 when subtraction is performed. The operation thus performed becomes A , plus the 1’s complement of B , plus 1. This is equal to A plus the 2’s complement of B . For unsigned numbers, that gives A - B if A Ú B or the 2’s complement of 1B - A2 if A 6 B. For signed numbers, the result is A - B, provided that there is no overflow. The addition and subtraction operations can be combined into one circuit with one common binary adder by including an exclusive-OR gate with each full adder. A four-bit adder–subtractor circuit is shown in Fig. 4.13 . The mode input M controls the operation. When M = 0, the circuit is an adder, and when M = 1, the circuit becomes a subtractor. Each exclusive-OR gate receives input M and one of the inputs of B . When M = 0, we have B { 0 = B. The full adders receive the value of B , the input carry is 0, and the circuit performs A plus B . When M = 1, we have B { 1 = B and C0 = 1. The B inputs are all complemented and a 1 is added through the input carry. The circuit performs the operation A plus the 2’s complement of B . (The exclusive-OR with output V is for detecting an overflow.) It is worth noting that binary numbers in the signed-complement system are added and subtracted by the same basic addition and subtraction rules as are unsigned numbers. Therefore, computers need only one common hardware circuit to handle both types of arithmetic. The user or programmer must interpret the results of such addition or subtraction differently, depending on whether it is assumed that the numbers are signed or unsigned. When two numbers with n digits each are added and a sum is a number occupying n + 1 digits, we say that an overflow occurred. This is true for binary or decimal numbers, signed or unsigned. When the addition is performed with paper and pencil, an overflow is not a problem, since there is no limit by the width of the page to write down the sum. Overflow is a problem in digital computers because the number of bits that hold the number is finite and a result that contains n + 1 bits cannot be accommodated by an n -bit word. For this reason, many computers detect the occurrence of an overflow, and when it occurs, a corresponding flip-flop is set that can then be checked by the user. The detection of an overflow after the addition of two binary numbers depends on whether the numbers are considered to be signed or unsigned. When two unsigned numbers are added, an overflow is detected from the end carry out of the most significant position. In the case of signed numbers, two details are important: the leftmost bit always represents the sign, and negative numbers are in 2’s-complement form. When two signed numbers are added, the sign bit is treated as part of the number and the end carry does not indicate an overflow. An overflow condition can be detected by observing the carry into the sign bit position and the carry out of the sign bit position. If these two carries are not equal, an overflow has occurred. This is indicated in the examples in which the two carriers are explicitly shown. If the two carriers are applied to an exclusive-OR gate, an overflow is detected when the output of the gate is equal to 1. For this method to work correctly, the 2’s complement of a negative number must be computed by taking the 1’s complement and adding 1. This takes care of the condition when the maximum negative number is complemented. The binary adder–subtractor circuit with outputs C and V. If the two binary numbers are considered to be unsigned, then the C bit detects a carry after the addition or a borrow after subtraction. If the numbers are considered to be signed, then the V bit detects an overflow. If V = 0 after an addition or subtraction, then no overflow occurred and the n -bit result is correct. If V = 1, then the result of the operation contains n + 1 bits, but only the rightmost n bits of the number fit in the space available, so an overflow has occurred. The 1n + 12 th bit is the actual sign and has been shifted out of position.
