Electronics Tutorial #5 - Ohm's Law Pt 2 - Application:LED Resistor, Voltage Divider, Current Shunt

A tutorial on practical applications of George Ohm's law for basic electronics and the relationship between current, voltage and resistance. Want a calculator? : http://astore.amazon.com/m0711-20?_en... -------------------- Click "Show more" ------------------------------ My website and forum:- http://www.mjlorton.com Donations and contributions:- http://www.mjlorton.com My techie channel MJLorton - Solar Power and Electronic Measurement Equipment -    / mjlorton   My Techie Amazon Store: http://astore.amazon.com/m0711-20 My other channel VBlogMag - For almost any topic under the sun! -    / vblogmag   My VBlogMag Amazon Store: http://astore.amazon.com/vblogmag-20 ----------------------------------------------------------------------- Ohm's law states that the electrical current (I) flowing in an circuit is proportional to the voltage (V) and inversely proportional to the resistance (R). Therefore, if the voltage is increased, the current will increase provided the resistance of the circuit does not change. Similarly, increasing the resistance of the circuit will lower the current flow if the voltage is not changed. The formula can be manipulated so that the relationship can easily be seen for all of the three variables. In this video: I go through practical applications of Ohm's law: current shunt, voltage divider, resistor values for LED, Arduino voltmeter, potentiometer. I demonstrate my Texas Instruments TI-30XS Multiview Calculator which can make calculating formulas a little easier. How to work out resistance in series and parallel? How to work out current in a circuit? What is voltage / volt drop? What is a resistor? Power calculations. How to calculate power in a resistor? Topics for future videos in this series: Ohms law, resistance, power, energy Electronic components - diodes, transistors, FETS, capacitors, digital logic gates, integrated circuits, 555 timer. Series and parallel circuits Op amps and feedback
