Structural Engineering & Construction Situation 12 (PH)

PAST BOARD EXAM PROBLEMS Structural Engineering & Construction Situation 12 Given the following date: Bolt diameter = 20mmø Bolt hole diameter = 23mmø Plate thickness = 25 mm Bolt shear strength Fvb=120 MPa Bolt bearing strength Fpb=480 MPa Plate shear strength Fvp=138 MPa Fy = 250 MPa & Fu = 400 MPa 1. Determine the max. load P based on the shearing strength of bolts. (339.3 kN) 2. Determine the max. load P based on the bearing strength of plate (2160 kN); and 3. Determine the max. load P based on the tensile capacity of the plate (1125 kN). Credits: 1. Intro Template:    • (FREE) 2D Square Intro (60 fps - No Text) ...   2. Music: 2.1 Driven to Success by Scott Holmes, Source: http://www.freemusicarchive.org 2.2 Instrumental (Guitar) by Carl Ernest Tayag, check his channel:    / @ninja35ful   3. Reference for the problem: Civil Engineering Reference for Licensure Examination, Volume 4, 1st Edition by DIT Gillesania (GERTC Review). Comment your suggestions or questions here. Thanks for watching! Subscribe now for more videos and click the bell icon for notifications. God bless! :) #SEC #CEBox #CivilEngineering #Engineering #ceboardexam #boardexam #prc #review #CivilEngineeringLicensureExam #structuralengineering #stem #engineeringlife #stemlife
