Igus Chain RBR rotary motion 10-4-048.048-0 55 links no cables Clockwise rotation seems to work just fine. Counter-Clockwise rotation, however, can cause the Igus chain can "Bunch up" in an undesirable way. Both the inner and outer guides have "shelves" to support the chain. Igus would typically use two intermediate guides to ensure proper behavior, but I don't have room. A couple of ideas. 1) perhaps installing the wires (cables) will increase the stiffness and improve the behavior. 2) This is a symmetric RBR chain meaning it can turn the same amount in each direction, e.g. +25° and -25°. But perhaps the behavior would be better if it was machined to +25° and -6° so that it cannot back-bend so far.
