SCREW GAUGE LIVE EXPERIMENT IN CLASS BY MS SIR @GRAVITON ACADEMY,PATNA,MEDICAL IIT FOUNDATION #career #screwgauge #pw #pw_motivation #graviton A quick guide on how to read a micrometer screw gauge. Similar to the way a vernier caliper is read, a micrometer reading contains two parts: the first part is contributed by the main scale on the sleeve the second part is contributed by the rotating vernier scale on the thimble Measurement Reading Technique For Micrometer A typical micrometer screw gauge The above image shows a typical micrometer screw gauge and how to read it. Steps: To obtain the first part of the measurement: Look at the image above, you will see a number 5 to the immediate left of the thimble. This means 5.0 mm. Notice that there is an extra line below the datum line, this represents an additional 0.5 mm. So the first part of the measurement is 5.0 + 0.5 = 5.5 mm. To obtain the second part of the measurement: Look at the image above, the number 28 on the rotating vernier scale coincides with the datum line on the sleeve. Hence, 0.28 mm is the second part of the measurement. You just have to add the first part and second part of the measurement to obtain the micrometer reading: 5.5 + 0.28 = 5.78 mm. To ensure that you understand the steps above, here’s one more example: Micrometer-5 First part of the measurement: 2.5 mm Second part of the measurement: 0.38 mm Final measurement: 2.88 mm Compensating For Zero Error In a nutshell Use the following formula: Correct reading = Obtained reading – Zero error where zero error can be either negative (the “0” marking on the thimble is above the datum line) or positive ( the “0” marking on the thimble is below the datum line ) Explanation Now, we shall try with zero error. If you are not familiar on how to handle zero error for micrometer screw gauge, I suggest that you read up on Measurement of Length. micrometer with zero error The reading on the bottom is the measurement obtained and the reading at the top is the zero error. Find the actual measurement. (Meaning: get rid of the zero error in the measurement or take into account the zero error) Measurement with zero error: 1.76 mm Zero error: + 0.01 mm (positive because the zero marking on the thimble is below the datum line) Measurement without zero error: 1.76 – ( + 0.01 ) = 1.75 mm The subtraction logic is similar to the method explained in How to read a vernier caliper. You can take a look and comment below, if you encounter any difficulties.
