Installing STP Cat6A RJ45 Keystone Jack Easily by CRXCabling’s Guide

Learn how to install the Cat6A STP toolless keystone jack with CRXCabling's easy-to-follow guide! In this video, we take you through each step of the process: stripping the Ethernet cable, sorting out the braid, cutting off the aluminum foil layer, wiring according to the T568A or T568B map, following foolproof hints to install the cap on the linear shielded keystone jack, pressing the RJ45 jack, and using a cable tie to secure it. This Cat6A toolless STP RJ45 keystone jack not only simplifies installation but also supports PoE++ (IEEE802.3 bt) devices up to 100W and meets UL verification, RoHS & Reach compliance standards, making it an ideal choice for structured cabling solutions. The linear Cat6A STP toolless keystone jack eliminate the need for a traditional termination tool. While the installation process is simplified and tool-free, we recommend using the handy pressing tool for quicker results. Want to learn more about how to install keystone jack? Subscribe to our channel then you won't miss any assembly guides. Feel free to visit our website through the link below for expert information from CRXCabling! #rj45 #keystonejack #toolless #guidlinerj45 #crxconec #crxcabling #toollessinstallation #networkcabling #structuredCabling #techtutorials #PoEdevice #RJ45plug #Cat6akeystonejack Product Links: ✔️4PPoE FTP Tool-free Shuttered Cat.6A keystone RJ45: https://cabling.crxconec.com/en/produ... ✔️Handy Keystone Jack Pressing Tool: https://cabling.crxconec.com/en/produ... Website: https://cabling.crxconec.com/ Linkedin:   / crxcabling   Catch us up on E-mail, Feel free to get more information ．annie@crxconec.com All CRXCabling Products https://cabling.crxconec.com/en/categ... Learn more in our CRXCabling Blog! https://cabling.crxconec.com/en/crx-b... Video Time Codes: 00:00 Intro 00:07 Overview 00:10 Remove cable jacket 00:21 Sort out the braid & alminum foil 00:35 Cut off the alminum foil layer 00:43 Put cap in 00:49 Wiring map 01:19 Cut off excess wires 01:31 Install on keystone jack 01:37 Use handy pressing tool compress keystone jack 01:43 Wrap the braid 01:46 Cable tie to fix and cut off 01:55 Assembly Complete
