Floor Flatness and Floor Levelness analysis based on 3D scan data using ARES Commander and Undet.

Learn how to analyze floor flatness and levelness using point cloud data! In this step-by-step tutorial, you'll discover: 1️⃣ How to slice and clean point cloud data using the Clip by Rectangle tool for a clear floor view. 2️⃣ Set up colouring by plane to visualize floor deformations with fixed-size intervals (e.g., 1cm or 5mm). 3️⃣ Use annotation blocks to snap to point cloud points and display Z-values, helping you document precise measurements. 4️⃣ Create and drape a grid of snapping blocks over the point cloud for detailed analysis. 5️⃣ Generate a 2D heat map to illustrate floor flatness. 6️⃣ Compare as-built point clouds with design models using Model Inspection Coloring to identify discrepancies. This guide simplifies complex workflows, ensuring accurate and efficient results for your floor analysis projects. Need the snapping blocks used in the video? Contact me, and I'll share them with you! 🔔 Subscribe for more tips on 3D laser scan data workflows, point cloud analysis, and BIM deliverables! Software used: https://www.undet.com/undet-products/... #Pointcloud #Undet #Ares #PointCloudToCAD #scan2bim #3dscanning #scantocad #HeritagePreservation #surveyor #surveying #AREScommander
