YAMAHA RIVAGE PM10 DIGITAL MIXING CONSOLE - EXPERIENCES

#Digital mixing console Perfecting the Art of Live Sound Yamaha's Rivage PM10 (YAM-PM10) is a Large Format Digital Mixing System that has become the standard in large-scale live sound applications because of its unequalled sound, operation, functionality, reliability, expandability, and more. The Yamaha "PM brand" continues to bring true innovation to the developing live sound scene. A basic RIVAGE PM10 system consists of the DSP-R10 DSP engine where all the signal processing magic actually happens, the CS-R10/CS-R10-S control surface for intuitive hands-on operation, one or more I/O Rack units for input and output connections, and one or more network cards for network connectivity. The flagship RIVAGE PM10 system also allows DSP mirroring for maximum dependability in mission critical applications while providing the capacity needed for large-scale setups. Preamplifiers with analog input stages that take the Yamaha "natural sound" concept to new heights, as well as digital sections with immaculate VCM-technology models of Rupert Neve Designs transformer and SILK processing circuitry that offer outstanding musicality and atmosphere. Then there's the Dante audio network from Audinate, already standard in CL and QL series digital consoles as well as a range of other Yamaha pro audio products. Dante-equipped Rio3224-D2 and Rio1608-D2 I/O Racks and the HY144-D audio interface card can be combined to provide natural sound input at full RIVAGE PM series quality. Features: Hybrid Microphone Preamplifiers: A Solid Foundation for Superior Sound VCM Technology Models SILK Processing by Rupert Neve Designs Channel EQ and Compression Refined to Unprecedented Levels Plug-in Effects Include Rupert EQ/Comp, TC Electronic Reverb, and More Touch Screen and Fader Strip Merge for Intuitive Control A Monitor Section to Match Any Job Overlay Filter for Rapid Response to Sudden Changes Specifications for the #Yamaha #Rivage PM 10 Mixing Capacity 44.1/48/88.2/96 kHz 144 input channels 72 Mix buses, 36 Matrix buses Stereo buses A and B (or Mono bus) Cue A/B, Monitor A/B Control Surface (CS-R10) Display 15” touch panel x 2 Faders 38 (12+12+12+2) Selected Channel section comprehensive channel parameters Custom Fader banks 6 x 2 on each bay User Defined keys 12 x 4 banks User Defined knobs 4 x 4 banks Touch and Turn knobs 2 Analog I/O 8 in / 8 out Slot 2 MY slots AES/EBU 4 in / 4 out (with SRC) Ports GPI (8 in / 8 out), Word Clock Out, MIDI In/Out, 5 USB (1 for 2-track recording), Video Out (DVI-D) Power supply dual redundant power supply built-in Dimensions (WxHxD) 1,549 x 417 x 848mm Net Weight 85 kg (187 lbs) DSP Engine (DSP-R10) Slot 2 MY slots, 4 HY slots (TWINLANe, Dante) Ports GPI (8 in / 8 out), Word Clock In/Out, MIDI In/Out, Remote, TC IN, Fault Output Power supply dual redundant power supply built-in Dimensions (WxHxD) 480 x 232 x 490.8mm (5U rack size) Net Weight 20 kg (44 lbs) I/O Rac k (RPio622) Slot 6 RY slots, 2 MY slots, 2 HY slots (TWINLANe, Dante) Ports Word Clock In/Out, Fault Output Power supply dual redundant power supply built-in Dimensions (WxHxD) 480 x 455 x 489.7mm (10U rack size) Net Weight 30 kg (66 lbs) Input Channel A/B, Gain Compensation, Digital Gain, HPF, LPF, 4-band PEQ, 2 Dynamics, Delay, 2 insert points (x4 daisy-chain), Direct Out Output Channel HPF, LPF, 8-band PEQ, Dynamics, Delay (on channel and port), 2 insert points (x4 daisy-chain) Scene Memory Number of scenes 1000 Functions Recall Safe, Focus Recall, Fade Time, Preview, Overlay Filter, Isolate DCA/Mute Group 24 DCAs, 12 Mute Groups Plug-ins 384 plug-in slots (The maximum number of plug-ins used at a time varies depending on the plug-in types) 45 types of plug-ins GEQ/PEQ 48 racks (96 for Flex15GEQ and 8-band PEQ) 31-band GEQ, Flex15GEQ, 8-band PEQ Recording 2-track USB recording (MP3 and WAV) Multitrack recording and Virtual Soundcheck via Dante (option) I/O Network (TWINLANe) 400 channels @ 44.1/48/88.2/96 kHz, 32-bit Network latency 11 samples at 44.1/48 kHz, 12 samples at 88.2/96 kHz Topology ring for network redundancy Recommended cable Neutrik opticalCON DUO multimode fiber Console Network Topology ring for network redundancy Cable CAT5e or better (etherCON) Dante (HY144-D) 144 in / 144 out @ 44.1/48/88.2/96 kHz, 32-bit Cable CAT5e or better (etherCON) Application Software RIVAGE PM10 Editor (Windows) Planned Functions in Future Update Engine Mirroring / Engine Cascade / Dual Console / Event List (Timecode chase) / Nuendo Live Remote / RIVAGE PM10 #StageMix /
