PRIMO HTrio Temperature Sensor Probe Replacement & Defrost Water Cooling Tank (VISUAL)

How to Fix PRIMO HTrio Coffee K-Cup Water Dispenser (Bottom Loading) Symptoms: Hot Water (Works) Coffee Maker (Works) Cold Water (Does Not Work / Possibly Frozen) Tools Used: Screwdrivers: Slotted & Phillips Pliers X-Acto Knife Office Tape Electric Tape New Temperature Sensor Probe Part I - Temperature Sensor Probe Replacement 1. Turn off Cold & Hot Water Switches behind Water Dispenser 2. Unplug Dispenser electric cord from wall 3. Unscrew the Black Metal Coils, Black Plastic Cover & Keurig Pod Holder as shown. Coils will not be completely removed only provides more working space. Keurig Pod holder will come completely off. Don't be afraid to pull off. It snaps back on after. Carefully unplug the power cable that's attached from the Keurig Pod Holder to the front circuit board. 4. Find small metal box containing control board next to the water cooling tank. Unplug red, yellow, brown & blue cables to provide more work space & flexibility. Take pics of any cables you plan to unplug to remember how to restore after you finish. 5. Cut portion of the foam around the little water cooling tank as shown to access the Temperature Sensor Probe. We will re-tape once finished. 6. Pull out Temperature Sensor Probe and trace it back to the front circuit board. You will see it has a blue base connection at the circuit board. Unplug cable at blue base. Cut off the Temperature Sensor Probe (Metal Part) we just pulled out (leaving the blue base connection intact on the cable). On your new Temperature Sensor Probe cable, cut off the white base (leaving the Temperature Sensor Probe intact on the cable) Splice the old & new cables. You should have the blue base on one end and the new Temperature Sensor Probe on the other. Reconnect to the circuit board & bottom of water cooling tank. Part II - Defrost Water Cooling Tank 7. Use flat head screwdriver to loosen & lift off 4 tabs from water cooling tank lid. 8. Fill up water cooling tank with hot water to melt off all ice. Wash hands then remove all ice chunks inside tank. After removing ice chunks, empty any water inside the tank by dispensing water into a cup like you normally would from the front. Add another cup of hot water inside the tank to make sure all ice frost is melted off and dispense again from the front. 9. FINALLY, put everything back together. Use tape to restore the foam piece around water cooling tank. Retrace your steps to not forget any unplugged cables. Don't forget to turn on the Cold/Water switches before plugging your PRIMO HTrio back into the wall! Buy Temperature Sensor Probe on AMAZON! DROK 10K Temperature Sensor Probe, 5pcs 1 Meter Waterproof Temp Sensor Probe, Stainless Steel 3950 NTC Temp Sensor Probe, Digital Temperature Transmitter Extension Cable
