etrailer | Detailed Breakdown of the Curt Trailer Connector Adapter with Backup Alarm

Click for more info and reviews of this CURT Custom Fit Vehicle Wiring: https://www.etrailer.com/Custom-Fit-V... Check out some similar Custom Fit Vehicle Wiring options: https://www.etrailer.com/dept-pg-Cust... https://www.etrailer.com Don’t forget to subscribe!    / etrailertv   Full transcript: https://www.etrailer.com/tv-Demo-Curt... Man: Today we're going to be taking a look at Part Number C57102. This is a Curt Trailer Connector Adapter with a backup alarm. This is 4-way, the 7-way round and 4-way flat. The multi-function vehicle end connector is going to convert any 4-way flat connector vehicle end plug to a combination of a 7-way outlet which is going to be this portion right here. And a 4-pole flat outlet. It's also going to feature the integrated backup alarm and it's going to have three LED lights on there as well. This is designed to connect to a 4-way flat plug on your vehicle. You're going to have the connection right here to make that appropriate connection. It is going to require additional wiring for the use of brake, power, and accessory leads. All of the brake or . excuse me. All the wires here included in the harness or the adapter are going to have the appropriate connectors on here. You're going to have three of them that are going to have the butt connectors and then the white is going to be your ground and that's going to have the ring terminal on there that will need be attached with a self-tapping screw. So again this is going to supply your 7-blade RV connector right here as well as a 4-way flat trailer connector. It's going to have the nice dust cap that goes over the connection points to prevent them from any type of corrosion. And then on the 7-way connector it's got the nice spring loaded lid that's going to protect the connection points as well. Now this is going to be constructed of a durable plastic construction. It's going to come with a mounting bracket and the necessary hardware to mount the connector to the actual bracket. You will need the hardware to mount the bracket to the vehicle, that is going to be sold separately. Through these holes right here that's going to connect using two number 10 half inch self-tapping screws. You can also use a number 10 half inch self-tapping screw to mount the ground connection with the ring terminal here on the end of the white wire. Now to go over the wire functions real fast with you, the yellow wire is going to be for the reverse lights. Your blue wire is going to be for the brakes. The black wire is going to be for 12 volt power and then your white wire is going to be for your ground connection and then you're going to have the four way connector that's going to plug into the existing vehicle 4-way connector. Once you have all those connections made, you're going to have full use of your 7-way connector right here as well as the 4-way flat connector right here. I'm going to show you how it mounts with the bracket. Just run all the wiring through the slots there, feed your 4-way flat through there as well. Now the holes in the bracket are going to line up perfectly with the holes here on national connector. Now that's going to be able to mount to the rear of your vehicle. It's going to hold it place and you have a little area here on the side of the bracket for your 4-way connector as well so it's going to stay right there next to the 7-way connector. That bracket is going to hold it in place. So real quick I just want to go ahead and show you the function here of the backup alarm. I'm going to go on and make our necessary connections and then you can see how that operates. Sends out a nice strong signal. It's really loud. You'll be able to see the lights flash as well. I'm going to activate the reverse function (beeping sound). That's going to sound and flash anytime the reverse function is activated on your vehicle. That's going to do it for today's review of Part Number C57102. This is the Curt Trailer Connector Adapter with the built in backup alarm. .
