PSAD SITUATION 136: Pattern Loadings on Four-Span Continuous Beam | CELE November 2021

CELE Past Board Exam Problem To learn more, enrol now to iReview Tutorial and Review Center: https://www.facebook.com/share/1AC24W... SITUATION: Beam ABCDE is to be analyzed for maximum forces at ultimate conditions. The beam is simply supported at A, B, C, D, and E. Factored loads: Dead load = 15 kN/m Live load = 19 kN/m L = 8 m 1. Determine the maximum shear (kN) at B. A. 167.08 C. 158.60 B. 165.10 D. 172.85 2. Determine the maximum reaction (kN) at B. A. 323.06 C. 402.36 B. 332.66 D. 345.25 3. Determine the maximum positive moment at span AB (kN-m). A. 181.86 C. 216.73 B. 242.05 D. 195.22 Thanks for watching! Comment for questions and suggestions for future lecture in this series. Subscribe and hit the bell button to be notified for future posts. Check out our Review Center: https://www.facebook.com/share/1AC24W... #civilengineering #boardexam #engineering #structuralanalysis #structuralengineering #CivilEngineeringLicensureExamination #PRC #PSAD #loadanalysis #theoryofstructures #influencelines #CELESeptember2025
