SMALL SIZE DRILLING RIG STORM

#drillingrig#welldrilling#smallsizedrillingrig#storm Products webpage https://storm-m.com Hello. We are present the small size drilling rig Storm 20. __________________________________________________________________ It is possible to execute the next types of drilling works: -well-drilling (by the method of flushing), diameter up to 200 mm and in 120 meters depth. For the drilling with flushing is used the rotator with swivel. Rotator with a swivel has frequency of rotation to 240 rpm and torque up to 550 Нм. Speed of the drilling with the method of flushing makes to 20 meters per hour and depending on a type and hardness of soil. It is possible the auger drilling. For this purpose it is enough to replace rotator with a swivel on rotator for the auger drilling. Rotator for the auger drilling has frequency of rotation up to 120 rpm and torque up to 1100 Нм. Replacement of rotator takes near one minute. Replacement of rotator can execute one man. We will bring parameters over of augers drilling: -auger drilling diameter 105 mm, in 35 meters depth; -auger drilling diameter 135 mm, in 25 meters depth; -auger drilling diameter 180 mm, in 15 meters depth; -auger drilling diameter 320 mm, in 6 meters depth; Speed of the auger drilling makes up to 30 meters per hour depending on the diameter of tool and hardness of soil. In base, drilling rig Storm 20 equipped by one of rotator at client choice. Other rotator can be purchased additionally. __________________________________________________________________ The drilling rig can be equipped with two types of engines: an air-cooled gasoline engine or a water-cooled diesel engine. In both cases, the engine power is 20 hp. A diesel engine is more economical, but requires more attention when servicing. Drilling rig used double-flow hydraulic scheme, due to it provivded constancy of speed and effort of rotation, and similarly speeds and efforts of raising/lowering of tool. The first hydraulic pump manages rotator, the second hydraulic pump manages the hydrocylinder of raising-lowering of tool. In the hydraulic system set the air-oil heat-exchanger. Due to a heat-exchanger the protracted work is possible at the high temperature of environment up to 40 degrees. The system is equipped by a thermostat that includes the additional cooling automatically. The professionally projected hydraulic scheme allows to get maximal efficiency during work. Assembling of drilling rig Storm 20 carried out only from quality components. The construction allows to use the hydraulic station for the drive of any other hydraulic tool. It is possible dismantling of the mast with rotator. At that rate hydraulic station weighs less than, has less sizes. Optional drilling rig may be equipped by two or by four hydraulic outriggers. __________________________________________________________________ The frame of the drilling rig keeps a large reserve of durability. It allows to execute work with high overload in the protracted term of exploitation. Compact sizes make possible mounting the drilling rig on many types of undercarriage such as: automobile trailer, pickup or truck. The drilling rig Storm is completed the set of awaiting-parts such as: hydraulic filter, air filter for engine, oil filter for engine, sealing for hydraulic cylinders, sealing for swivel. __________________________________________________________________ The drilling rig Storm is able to work in the semi-automatic mode. It is necessary only setting or removal of tool. In the interval of time from replacement to replacement of tool it is possible work of drilling rig only at visual control for drilling process. Simplicity of construction allows to execute technical service in the field terms. __________________________________________________________________ The sale of the drilling rig is possible in different options: choice of rotator . Choice of petrol or diesel engine. Choice of necessary tool. __________________________________________________________________ Drilling rigs Storm always are in stock. Delivery is possible in any country. Delivery is possible by car, air and sea transpor. For this purpose you are enough to send a request on e-mail specifying next parameters: 1. Types of planned work: (water well drilling, auger drilling, all types of work). 2. The depth and diameter of drilling for each type of work performed, or for one type. 3. The need for a spare tool (indicate length or quantity). 3. The need for a mud pump to supply mud (yes or no). 4. Type of engine (gasoline or diesel). 5. The need for hydraulic outriggers indicating the height of the landing gear (indicate quantity and height).
