SDRplay AM (MW) RSPduo Diversity demo

Italo, IK3UMZ demonstrates AM (MW) diversity tuning with the dual tuner RSPduo and SDRuno software from SDRplay. Italo writes: "Here’s what you can do with “diversity” : Same frequency , but with two different transmitters ; with different distances and therefore travelling different paths . With “diversity” you can discriminate using the phase difference and therefore the signal . Set-up RSP-DUO Antenna 1 orthogonal magnetic loops diameter 1m Antenna 2 delta loop 20m, approx 40m away from Antenna 1" In the video you see how Italo uses the manual phase control to select between the two transmissions, both on 918kHz AM choosing to listen to either one or the other. This is just one way of using the diversity feature. It can also be used in automatic mode for calculating and maintaining the best of both signals using "Maximum Ratio Combination" . It can also be used to help reduce unwanted noise sources. As well as providing Diversity tuning, the RSPduo is ideal for monitoring 2 antennas simultaneously in real time since you can display the two spectrum displays on the same screen - as shown 5 minutes into this video:    • Setting up SDRuno to view both RSPduo tune...   For more on diversity tuning, visit our Documentation and Video library and search for Diversity (for both SDRplay and 3rd Party videos): https://www.sdrplay.com/apps-catalogue/ (an example link is: https://www.sdrplay.com/more-about-di... ) The RSPduo data sheet can be downloaded from here: https://www.sdrplay.com/rspduo/ This is one of many video guides from SDRplay - makers of the RSP family of SDR radios. See the full list of SDRplay videos and applications documents on: https://www.sdrplay.com/apps-catalogue/ The RSP family of SDRs from SDRplay cover 1kHz to 2 GHz with no gaps and give up to 10MHz spectrum visibility. SDRplay is a UK company. The RSP SDR receivers are made in the UK and can be purchased for worldwide delivery directly from http://www.sdrplay.com/ (click on purchase and select your country to view shipping costs) or you can buy from any of our worldwide resellers listed here: http://www.sdrplay.com/distributors/ Many of the resellers offer local free shipping and/or local language technical support. The SDRplay YouTube Channel is:    / sdrplayrsp
