How to setup the Pi1541 with an E-mu SP 12 Turbo

Here's how to set up a Pi1541 Commodore 64 Floppy disk emulator using a Raspberry Pi Zero W and PiDRIVE ZERO Raspberry Pi HAT with your E-mu SP 12 Turbo. I go over how to save and load sounds and sequences, where to buy the items in this video and how to set it all up. No configuration should be necessary once you burn my SD card image to yours. Please note I'm using a 2GB card, so this might effect the size of your SD card. Cheers. 1. Get the PiDrive Zero Pi HAT 2. Get a Pi Zero W with GPIO pin headers 3. Get a Serial cable 4. Get a Micro SD Card 5. Seat the Pi Hat into the GPIO pin headers of the Pi Zero 6. Format SD card for FAT32 7. Download my SD card .img file (link below) 8. Extract the PiZero Image.zip 9. Download Win32 Disk Imager 10. Write .img file to SD card 11. Securely eject SD card 12. Insert the burn SD card into the Pi, plug in power 13. Plug in serial cable into SP 12 Turbo and Pi Hat 14. Button layout from top to bottom: -Enter -Up -Down -Jump out folder -Jump in folder 15. To save sound: on Pi Hat, Jump in 1541 folder \ select - SoundDisk.G64 \ Hit Enter \Disk in Pi is now loaded On SP 12: Hit Casette / Disk \ Press: 2,2, Enter 16. To Load Sound: On PiHat - Select soundisk.G64 (containing sound) \ Hit Enter On SP 12: Hit Casette / Disk \ Press: 2,5, Enter 17. To Save Sequence: on Pi Hat, Jump in 1541 folder \ select - SequenceDisk.G64 \ Hit Enter \Disk in Pi is now loaded On SP 12: Hit Cassette / Disk \ Press: 2,1, Enter 18. To Load Sequence: on Pi Hat, Select - SequenceDisk.G64 \ Hit Enter \Disk in Pi is now loaded On SP 12: Hit Cassette / Disk \ Press: 2,3, Enter Notes: If you need more disks, simply make copies of the existing disks on your PC. Sounds disk 1 and disk 2 have some drums and a horn sample. You may need to format some of these disks. Simply hit 2,0, Enter on the SP12. All background beats were produced by me. I have not uploaded to soundcloud in many years:   / eclectic-flex   Links: PiDRIVE ZERO https://www.ebay.com/itm/PiDRIVE-ZERO... Raspberry Pi Zero (Find a seller in your Country for faster delivery): https://www.ebay.com/itm/Raspberry-Pi... Serial Cable for Commodore 64 C64 Disk Drive 1541 3 ft DIN 6 PIN: https://www.ebay.com/itm/Serial-Cable... SD Card Image File: https://mega.nz/file/OclykaCa#7-Tu_V1... Win32 Disk Imager: https://sourceforge.net/projects/win3... Pi1541 Resources: https://cbm-pi1541.firebaseapp.com/
