Blade of Screw Conveyor | SolidWorks 3D Modeling & Assembly Tutorial

In this SolidWorks tutorial, I demonstrate how to design the Blade of a Screw Conveyor from scratch, using a combination of essential sketching tools, 3D features, and assembly techniques. This project showcases the step-by-step modeling process of various parts like the shaft, helical blade, pipe, sheet, and fasteners such as allen bolts and nuts. Features Used: Planes & References Helix/Spiral for blade path Sweep Boss/Base for the helical blade Extruded Boss/Base & Cut Revolved Cut Chamfer Sketch Tools: Line, Circle, Rectangle, Arc, Centerline Fully Defined Sketches Dimensions & Relations: -Equal, Concentric, Tangent, Horizontal, Vertical 🎨 Additional Tools: Appearances and Material Application Multiple View Orientations: -Isometric View, Top View, Side View, and more 🔧 Assembly: Components Assembled: Shaft, Blade, Pipe, Sheet, Allen Bolt, Nut Mates Applied: -Coincident, Tangent, Concentric, Copy with Mates This video is perfect for beginners and intermediate users who want to learn how to work with helix-based geometries and mechanical part assemblies in SolidWorks. Watch the full tutorial to understand how these tools come together to form a complete screw conveyor blade. 👉 Don’t forget to like, share, and subscribe to my channel thesolidworklad for more SolidWorks tutorials and machine design projects! #solidworks #screwconveyor #3dmodeling #mechanicaldesign #solidworklad #cad #helicalblade #assemblytutorial #solidworkstips #sheetmetal #machine #3danimation
