Modded NES Zapper working for LED TV with Duck Hunt

The mod: -De-soldered the photodiode LED from a Tomee Zapp -Soldered some legs on the photodiode on a 90 degree angle so it could reach the circuit board (I used the original photodiode from the step below to eyeball how long the legs should be to get the new photodiode in the correct position, roughly centered in the housing). Note that this step has to be done in the correct orientation (see pic below). The negative post on the cicuit board is on the right side of the gun (see the video at about 2:33). o LED anvil/negative example - http://www.theledlight.com/media/wysi... -Opened Zapper and bent the metal flaps away from the circuit board so I could de-solder -Replaced the original photodiode in the original NES Zapper with the one from the Tomee -No other modifications were done. I think the Tomee Zapp was so closely reverse-engineered that the circuit is basically the same (guessing on that point) Notes: -Works on two LED TVs but doesn't work with three older LCD TVs (non-LED) I tested -Worked even with scanlines and scaling enabled on the HiDefNES -Mod is not as good as an unmodified Zapper on a CRT TV (it only rarely worked, in fact) Links: Tomee Zapp - https://www.amazon.com/Tomee-Zapp-Gun... NESLCDMod - http://neslcdmod.com Everdrive N8 - https://krikzz.com/store/home/31-ever... HiDefNES - https://www.game-tech.us/product/hi-d... ElectronAsh has more insightful mod points about using a regular red LED as a replacement -   / 1043288461061640192
