Part 2: Beginners Guide to Designing a Functional Replacement Part in Onshape – Complete Workflow

In this episode of CAD That Works, I take the measurements and insights from the broken lever arm we reverse engineered in Part 1, and walk through the full CAD design process in Onshape. You'll see how I: Translate rough measurements into clean geometry Decide on constraints and dimensions for function Model with 3D printing and strength in mind This isn't about flashy renders — it's about designing real, usable parts that solve real problems. 🔧 Tools used: Onshape (browser-based CAD) Calipers, notes, and common sense 👉 If you missed Part 1 (the teardown & reverse engineering), check it out here: TBD Stay tuned for Part 3, where we’ll 3D print the part and test it in the actual vacuum sealer!
