Nonlinear Dynamic Analysis in Abaqus part 1

Our telegram channel for Abaqus and Q&A: https://t.me/abaqus_asist Our Telegram channel for FFS, Structure Integrity and the analysis of fixed equipment: https://t.me/ffs_asme_dnv_api_femex Our LinkedIn page:   / amirhossein-mirzabozorg-15443b47   If you want to be informed about our 50% discount codes and other announcements, join our Telegram channel or follow us in LinkedIn. Contact info for using our services: mirzabozorg71@gmail.com Comprehensive Abaqus Package:    • Comprehensive Abaqus Package   Including 39 hours of step-by-step tutorials. Step by step tutorials to do the impact analysis, quasi static analysis via dynamic steps and introducing ductile damage to the model:    • Impact Simulation of Composites and Fiber ...      • Static and Quasi-Static Analysis by using ...      • Damage Analysis of Notched Specimen in Ten...   Don’t hesitate to ask any questions you might have about the explanations presented in this video using the comments below. We try to answer all questions regarding the video details in the comments below. Sources of nonlinearity in structural mechanics simulations: Material nonlinearity Boundary nonlinearity Geometric nonlinearity Types of dynamic analysis: Linear: non of the sources of nonlinearity are included in the model like Frequency analysis Nonlinear: one or more sources of nonlinearity are included in the model like Crash, Explosion, Ultrasonic process, Machining process analyses To compare the results of linear and nonlinear dynamic analyses, two types of problems will be solved: 1) Geometric nonlinearity is not included (Nlgeom=off) 2) Geometric nonlinearity is included (Nlgeom=on) We will solve a problem using both procedures and compare the results. Moreover, the effect of the displacement value on the difference of the results will be investigated. In the following tutorial, I will solve the model using the Dynamic Implicit step and compare its results with the results obtained by the Dynamic Explicit step. Also, the necessity and the procedure of applying a filter to the obtained results (to remove the numerical noises) will be discussed in detail. #Abaqus #explicit #dynamic #dynamic_step #dynamic_explicit #Impact #Impact_analysis #nonlinear_analysis #nonilnear_dynamic_analysis
