PP ROPE MAKING MACHINE 4MM TO 8MM

Rope Range 4mm to 8mm Model SSE / 4T8-24 Strand Flyer RPM Max . 1600 Rope Flyer RPM Max. 800 Rope Lay Z Twist Range 30 to 90 TPM Twist Per Stand Adjustable Pay Of Package Size 250mm Diameter x 250mm Traverse Take Up Capacity 20Kgs (Approx.) Dimension ( LxWxH) 19’ X 7’1” X 7’4” Motor KW 11 KW Weight 2850 kg. ( Approx). KEY FEATURES Extra Yarn Tension Arrangement to control the ballooning. Power transmission by timing belts. Simple but Robust Design & Light Weight rotating Parts. Auto stop after yarn breakage to control Wastage. Digital length counter meter. Door Sensor Take up output on M.S. Bobbin. Anti Twisting Unit. User Friendly Design. OPTIONAL FEATURES A.C Frequency Drive. Direct Coling Head Increased take up capacity Increased pay off package MODEL SR NO. MODEL NO. NO OF PLY ROPE SIZE MM NO.OF PAY OF PACKAGES MOTOR KW WEIGHT KG DIMENSION LXWXH 1 SSE/4T8-12 3 4-8 4X3=12 7.5 2200kg 16'1"X5'3"X5'6" 2 SSE/4T8-16 4 4-8 4x4=16 9.3 2500kg 16'1"x7'1"x7'4" 3 SSE/4T8-18 3 4-8 6x3=18 9.3 2950kg 18'x7'1"x7'4" 4 SSE/4T8-24 4 4-8 6x4=24 11 3150kg 18'x7'1"x7'4" 5 SSE/4T8-24 3 4-8 8x3=24 11 3350kg 19'x7'1"x7'4" 6 SSE/4T8-32 4 4-8 8x4=32 15 3450kg 19'x7'1"x7'4" Note: Take up capacity and numbers of pay of pakages can be customized as per customer requirements. We reserve the right to change details/specification/equipment without any prior notice. CONTACT US SIGMA PLASTOMECH PLOT NO 302/1, GIDC, CHITRA, BHAVNAGAR-364004. CELL: +91 7490037888 #ROPEMAKINGMACHINE, #ROPE, #PPROPE, #PLASTICROPE, #ROPETWISTINGMACHINE,
