PicoSynthRF - Low Cost DIY 150 MHz RF Signal Generator

This is a very brief (90-second) video showing a 150 MHz signal generator project. It is low cost (about $25), uses currently easy-to-find components, and doesn't require any software compilation because it uses Python interpreted code. For printed circuit board (PCB) files, schematics, code etc., see the accompanying blog post here: https://community.element14.com/produ... . This project was created primarily to act as the local oscillator (LO) for a simple software defined radio (SDR) project, however it is general-purpose enough to have other uses. The output would benefit from additional external buffering, it cannot drive a 50 ohm load. It can drive a couple of logic gates however.
