REL #10 RTB2000, SDS2000x Plus and DSOX1000 Series Oscilloscopes, Episode 7: Signal generators

Episode 7: Signal generators (function generator, ARB, pattern generator, training signals) This is an episode of a functional comparison of the R&S RTB2000, Siglent SDS2000X Plus and Keysight InfiniiVision DSOX1000 oscilloscope series. The document with an overview of functions is available at: https://github.com/RudisElectronicsLa... Comments, corrections, additions etc. are welcome! 00:00 Start 07:02 Function generators: Specs comparison 09:29 … RTB2004 14:20 … SDS 2000X + 16:25 … DSOX1204G 20:08 Arbitrary Waveform generator (ARB): Specs comparison 23:15 … RTB2004 31:22 … DSOX1204G 37:53 Pattern generator 38:14 … RTB2004 43:28 Pattern generator: Specs comparison 44:45 … RTB2004 45:30 … DSOX1204G 47:27 Training signals: Infrequent glitch & waveform update test 54:49 Conclusions Episodes available or planned include: 1. Physical devices 2. User interface 3. Acquisition systems, channels, horizontal system & trigger 4. Tools 5. Bus decode 6. Analysis 7. Signal generators 8. Memory, history, search 9. Computer access and atomization 10 System features
