MS L14-M1 Multispan Touch Screen Process / Temperature Scanner: Instruction Guide

This instruction guide demonstrates the complete process and configuration of the Multispan MS L14-M1 8-Channel Touch Screen Process / Temperature Scanner. Learn how to connect, configure, and operate this industrial device, including sensor setup, low/high alarm management, Modbus communication, and general settings. Timestamp [00:01] Introduction [00:10] Backside Connections Overview (Supply & Communication) [00:36] Supported Sensor Types (Thermocouple & Analog) [00:51] Input Channel Wiring Examples [01:31] Relay Output Connections & Grouping [01:56] Accessing the Main Menu (Password 7373) [02:17] Sensor Configuration & Input Selection [03:13] Analog Input Range, Offset & Correction Factor [04:02] Alarm Management - Channel Grouping [05:00] Alarm Management - Group Relay Settings (Single/Double Relay) [06:38] General Settings - Real-Time Clock (RTC) [07:05] General Settings - Scan Time Adjustment [07:15] General Settings - Modbus Communication Setup (Password 2525) [08:00] General Settings - Main Menu Password Change [08:14] Live Display, Indicators, and Group Color Coding [09:09] Conclusion #Multispan #MSL14M1 #TemperatureScanner #ProcessScanner #InstructionGuide #TouchScreenScanner #MultispanSupport #Modbus #SensorConfiguration #AlarmManagement #PT100 #Thermocouple #420mA #010V #IndustrialAutomation #PLC #HMI
