BEND PIPE DESIGN CATIA V5 TUTORIAL.

What is a bent pipe? Bent pipes are classed by the severity of the bend: ¼ Bent, ½ Bent etc. the bend in the stem/mouthpiece makes the pipe more comfortable to hang and smoke hands free. A slight drawback to this design is moisture and saliva can run down the stem into the base of the bowl. In this tutorial, learn how to design bent tubes and pipes using the Rib, Shaft, Pad, Groove, Hole and Circular Pattern tool in CATIA V5. We’ll walk you through creating pipe with180° and 90° bends. As shown this video, you will finalizing your own design yourself.
