SCM/Olimpic S1000 Edgebander

SCMI OLIMPIC S1000 T-ERL, ... Production Edgebander with Pre-Milling & Corner Rounding. Specifications: Edge Capacity, 0.4 to 15 mm (0.016" to 5/8") for strip feeding. Panel Capacity, min. width 50 mm and 140 mm min. length, (2.0" and 5-1/2"). Panel thickness min./max. 8 - 60 mm (3/8" - 2-3/8"). Equipped With: Adjustable In-feed Fence: Manually pre-set with digital indicator and pneumatic panel spacing device. Pre-Milling Station, RT-E: Spindles 2 x 5.25 HP, 12,000 RPM, (1) with PLC controlled jump action and manual digital indicators positioning and Diamond Cutter-heads. Automatic Strip & Coil Feed Magazine: For straight/strip edges and 3 mm guillotine for coiled edge-materials. Gluing Station, Vc/1000: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. Pressure Section: Servo motor positioning, (4) pressure rollers, first larger, Teflon coated and powered.
