Add a datum notation to the Profile View of Civil 3D

jeewc3d.blogspot.com Civil 3D for Beginners https://www.udemy.com/course/road-des... Work With Civil 3D Alignments https://www.udemy.com/course/work-wit... Contact - jacdesigns95@gmail.com This tutorial explains how to add a datum title to the profile view in Civil 3D. First, select the profile view and go to the "Edit Profile View Style" option. You can either copy an existing style or modify the current one. Then, navigate to the "Title Annotation" tab and ensure the left axis title is selected. If it's not visible, go to the "Display" tab and turn on the left axis title. Change the title from the default (e.g., "Elevation") to "Datum." Apply the changes to reflect the update on the profile view. To adjust the position of the datum title, you can change its rotation and apply offsets for vertical and horizontal alignment. The Y offset controls vertical position, while the X offset moves it horizontally. You can also customize the text height and style to suit your drawing standards. Alternatively, if you want to keep the left axis title unchanged, you can reposition an unused title field (like from the bottom) and use it for the datum instead. This provides a clean and customizable way to annotate a datum in your profile view.
