Mako Pixhawk VTOL MC to FW Transition Flight Test 1 021717

I made some modifications on the original build to clean up the installation of some components. Major props to @dagar with the PX4 Dev team that has helped me tremendously! Removed the GPS folding stand to make room for the VTx. I also installed a Biteye FPV camera with built-in DVR and VTx for full OSD and telemetry functionality. Mounted the Pitot Tube in a 3D-Printed mount. - http://www.thingiverse.com/thing:405444 Relocated the 3DR Telemetry radio and antenna to the bottom of wing to give way for the GPS puck. The vertical fins were moved about 1.875" get it farther from the propellers and was able to just minimally notch it for prop clearance. The rear quad motors were turned 180 degrees so that the props are mounted on top. I was able to then remove the aft skid. Since Thrust to Weight ration only needed to be between 1.3 and 1.6, I changed the props to self-locking 3-bladed 9.4 x 5 Props that provides about 1.4 ratio that suffices for VTOL process. Original maiden flight:    • ** Revised and Updated ** Mako VTOL Transi...   Original build specs:    • Mako Pixhawk VTOL Conversion Maiden Flight...   There are still some tweaking that need to be done with parameters to hone in a more stable and reliable flight characteristics. Hopefully, all this will lead to good autonomous flight behavior. RMRC Mako PNP - https://www.readymaderc.com/store/ind... Pixhawk PX4 2.4.6 Flight Controller http://www.ebay.com/itm/251858758736?... PX4 Pro Stack http://px4.io/docs/quad-vtol-configur... NEO-M8N GPS 3DR Telemetry Eagle Tree Airspeed Microsensor v3 - http://www.eagletreesystems.com/index... EMax MT2216-810 kV - http://www.headsuphobby.com/Emax-MT22... ZTW Spider 12A Opto ESC - http://www.buddyrc.com/ztw-spider-12a... Jrelecs 9450 3-blade Self-locking Propeller - https://www.amazon.com/gp/product/B00... Lemon RC Satellite Rx Spektrum DX8 Tx Floureon 3S 11.1V 3000mAh 30C Lipo AUW: 1746g Close up takeoff ground footage clip from Darthgeese YouTube channel. Music: Clap Along by Audionautix - http://audionautix.com/
