ALM 6510 - Aluminium Profile Machining and Cutting Center

🛠️ALM 6510 is #8-axis #CNC controlled #machining center which is specifically designed to process any kind of #aluminium profiles in the market. The machine can do all operations on four sides of aluminium profiles such as #milling, opening key holes, hinge holes, handle holes, marking, #saw blade cutting etc. Key Features: ✔️Servo control system providing CNC motion at 8-axis ✔️Fully automated feeding, carrying, positioning, cutting and transferring units ✔️Performing operations on four sides of aluminium and PVC profiles such as milling, opening key holes, hinge holes, handle holes, marking, saw blade cutting etc. ✔️Pneumatic gripper for accurate positioning of the profile ✔️Automatically working horizontal and vertical clamping system ✔️Profile processing capacity with 1.600-1.800 running meter/ 8 hours ✔️Automatic conveyor unit with 7 pcs of profile loading capacity ✔️Servo controlled down-cutting saw blade with Ø550 mm dia. that rotates between the range of 45° and 135° ✔️Windows based PC and 15.6’’ LCD touch screen monitor ✔️Remote desktop connection and providing technical support ✔️Ability to perform milling and cutting operations at the same time ✔️User friendly interface software that is compatible with CAD programs ✔️Automatic frame and sash profile recognition system ✔️Automatic profile width and height dimension control system ✔️Automatic lubrication system ✔️Automatic tool spray cooling system ✔️Low pressure control for safety operations ✔️Interior LED lighting Product Link: https://www.yilmazmachine.com.tr/en/p... To subscribe to Yılmaz Machine channel👉    / yılmazmachinetv   To subscribe to Yılmaz Machine Instagram account 👉  / yilmazmachine
