VPPM-LK + CPX-AP-I-4IOL + IO-Link + CPX-AP-I-EP + CLogix + EthIP

This video describes how to establish a connection from a Festo VPPM Proportional Pressure Regulator Valve to a Festo CPX-AP-I-4IOL IO-Link Master which is connected via an AP-I network to a Festo CPX-AP-I-EP EtherNet/IP Master which is connected EtherNet/IP to an Allen Bradley PLC (Programmable Logic Controller). The control method of the Festo VPPM is via IO-Link. The sample code is programmed with RSLogix5000/Logix Designer software version v32.011. (0:01) Overview of Video content (1:20) Software overview from Festo website (8:18) Festo Automation Suite (FAS) and L5X Project Export for CPX-AP-I System Process Data (17:20) Webserver and L5X Project Export for CPX-AP-I System Process Data (19:38) RS5000/LogixDesign IMPORT of Festo Automation Suite (FAS) and L5X Project Export (23:02) RS5000/LogixDesign IMPORT of Webserver L5X Project Export (24:00) RS5000/LogixDesign Show difference between Festo Automation Suite (FAS) and Webserver L5X Project Export (25:18) RS5000/LogixDesign Importing CPX-AP-I System Process Data to End user PLC Project (28:00) RS5000/LogixDesign - Programming VPPM Process Data & Testing (38:26) RS5000/LogixDesign - Programming VPPM Hardware Status (EtherNet/IP and IO-Link) (46:40) RS5000/LogixDesign - Programming VPPM Diagnostics (52:50) Festo IO-Link Tool Software I have included a variety of application files (within a “zip” file) to accompany this video that can be retrieved at the following Google Drive link: https://drive.google.com/file/d/16RCO...
